Ancel Automotive 12V Vehicle Battery Tester

RM 299.00

Ancel Automotive 12V Vehicle Battery Tester..


Ancel BST200 Battery Tester adopts currently the world's most advanced conductance testing technology to easily, quickly and accurately measure the actual cold cranking amps capability of the vehicle starting battery, healthy state of the battery itself, and common fault of the vehicle starting system and charging system, which can help maintenance personnel to find the problem quickly and accurately, thus to achieve quick vehicle repair.


Main functions of BST200 battery tester include: battery test, cranking test, charging test and other additional functions.

BATTERY TEST is mainly targeted to analyze the battery healthy status to calculate the actual cold cranking capability of the battery and the aging extent, which provide reliable analysis evidence for the test and maintenance of the battery. It notifies the user to replace battery in advance when the battery is getting aged.

CRANKING TEST is mainly to test and analyze the starting motor. Through testing the actual required cranking current and cranking voltage of the starting motor, it can find out whether the starting motor works fine. There are several reasons why the starting motor is abnormal: lubricating system fault causing the starting loaded torque increasing or rotor friction of the starting motor causing the increasing friction of the starting motor itself.

CHARGING TEST is to check and analyze the charging system, including generator, rectifier, rectifier diode, etc., thus to find out whether the output voltage of the generator is normal, the rectifier diode works fine and the charging current is normal. Suppose one of the above mentioned parts is not in normal situation, it will lead to over charge or incomplete charge of the battery, thus the battery will be quickly damaged and also greatly shorten the using life of other loaded electrical appliance.

Usage scope: All car lead-acid starter battery, including regular flooded, EFB, AGM tablet battery, AGM winding battery, GEL battery, etc.

Suitable for: Automobile facory, garage, auto battery manufacturer, auto battery agent, educational institution, DIY enthusiasts, etc.

Test range: CCA100-800, 30-100Ah

Test result: SOH, SOC, CCA Value, IR, Starting & Charging system, etc.

Test standards: CCA, BCI, CA, MCA, JIS, DIN, IEC, EN, SAE, GB

**Tecnical Data**

Brand Ancel

Model BST200

Application 12V batteries

Test range 100-800 CCA

Voltage range 6V-16V DC

Weight 0.21kgs

Warranty 1 years

*Free shipping to whole Malaysia*

PRICE RM299.00*..(Ancel Automotive 12V Auto Battery Tester)..

*Price are inclusive 6% GST.
