i-Weld TIG 200P AC/DC Inverter Pulse Welding Machine

RM 3,600.00

i-Weld TIG 200P AC/DC Inverter Pulse Welding Machine..

Model GTAW 200P AC/DC


The i-Weld Pulse AC/DC 200 is technologically advanced and ruggedly constructed and tested for most production or fabrication environment, including tough shipbuilding application.


**Features**

✔ Welder Friendly controls

✔ Generator Friendly (Low KVA Requirement)

✔ High Frequency (H.F) Start/ Lift Start/ MMA Selector Switch for mode selection

✔ H.F Auto Cut Off for protection against accidental triggering

✔ MCB for fault protection & fuse for control circuit protection

✔ Gas pre/post flow time adjustment (for gas purging and cooling)

✔ Ease of maintenance

✔ Digital Display for easy setting of the current

✔ 2S/4S/ Fast Track Selector Switch for Trigger Hold and Quick Tacking

✔ Current limit, Under Voltage and Overload Protection

✔ Current Up/ Down Slope adjustment (for soft start and crater filling)

✔ Tungsten tip saving circuit (in LIFT mode, when the tungsten is shorted to work, only 10A current flows)


**Application**

. Tool / Die repair

. Vessel / Tank / Boiler Fabrication

. Train

. Maintenance

. Fabrication


**Specification**

Brand i-Weld

Model GTAW 200P AC/DC

Power Voltage AC 240V+15% (Single phase)

Frequency 50/60Hz

Rated Input Current : TIG - 32.5A / MMA - 43.5A

Output current 10 – 200A

No Load Voltage 44V

Rated Output Voltage : TIG 18V / MMA 28V

AC duty cycle 20-80%

Pulse duty cycle 10-90%

Post-flow time 0-10 S

Pulse frequency 0.5-5.0Hz

Basic Value current 5-200A

Arc initiation current 5-200A

Arc initiation way HF

Max. thickness 10mm

Attenuation time 0-15 S

Frequency 80%

Duty cycle 60% @ 40°C

Power factor 0.73

Insulation class F

Protection grade IP21

Weight 20kg

Dimensions 498 x 328 x 302mm

Warranty 12 months


**Included**

1. i-Weld GTAW 200P AC/DC Welding Machine

2. Welding Cable with Earth Clamp (100% Copper Cable)

3. WP-26 TIG Welding Torch

4. Reinforced Gas Hose


PRICE RM3,600.00..(i-Weld ideal innovative)..
