Nikon 24x Auto Optical Levels c/w Tripod & 5m Measuring Rod

Nikon 24x Auto Optical Levels c/w Tripod & 5m Measuring Rod..
Model AC-2S

**Features**
.Compact and lightweight
.Water-resistant construction
.Magnetic-dampened automatic compensator
.Horizontal tangent knobs with unlimited range
.Smooth, precise pointing and angular measurement
.Detachable eyepiece lens

AP/AC/AX Series auto levels are easy to set up and use All three models can attach to both flat-head and spherical-head tripods. Horizontal tangent knobs with an unlimited range ensure smooth, precise pointing and angular measurement, and you can operate them with either hand. The detachable eyepiece lens lets you use an optional diagonal eyepiece prism for working in extremely close or steep quarters.

Nikon optics effectively let in more light, so you see brighter, sharper images-especially in low-light conditions. The AP-8 model auto level features a 28x high-magnification telescope, the AC-2S has a 24x telescope, and the AX-2S has a 20x telescope. All three models offer minimum focusing down to 2.46 ft (0.75 m) for better performance in tight spots or on steep slopes.

**Specifications**
Model AC-2S
Telescope tube length 190 mm (7.5 in)
Image erect
Magnification 24x
Effective diameter of objective lens 30 mm (1.2 in)
Field of view 1°30' (2.6 ft @ 100 ft)
Minimum focusing distance .75 m (2.46 ft)
Stadia ratio 1:100
Stadia additive constant: 0
Level Vialsensitivity circular level 10'/2 mm
Standard Deviation (1 km double-run leveling) Without micrometer ±2.0 mm
Automatic compensator type wire-hung, magnetic damper
Compensation range ±16'
Setting accuracy ±0.5"
Diameter of circle 110 mm (4.3 in)
Minimum increment 1°/1 g
Reading estimation 0.1°/0.1g
Dimensions instrument L190 x H128 x W123 mm (7.5 x 5.0 x 4.8 in)
Carrying case 292 x 170 x 163 mm
Weight instrument 1.25 kg (2.8 lb)
Carrying case 1.2 kg (2.7 lb)
Warranty 1 years

PRICE RM1,599.00*..(Nikon at the heart of the image)..
*Price are inclusive 6% GST.
